EVO II Pro Enterprise V2
EVO II Pro Enterprise V2
- 20MP 1" CMOS sensor capable of 6k Ultra HD Videos
- Adjustable aperture range of f2.8 to f11
- 3x Lossless 16x Digital Zoom Capability
- With an expanded selection of accessories
- 360° obstacle avoidance with 19 groups of sensors
- Industry-leading 42 minutes flight time
- Transmission range of 8 miles
- 44 mph Max Speed
WORK LIKE NEVER BEFORE
Optimize your workflow with our toughest EVO II yet, bulked up with new accessories and camera features to
meet the demands of professionals in every industry from firefighting to construction. With a foldable design
that can be deployed in seconds and easy-to-use controls that can be operated with a single hand, the EVO II
Enterprise provides a surefire way to increase efficiency without increasing stress.
High-resolution Imaging
20MP 1"CMOS Sensor
3x Optical 16x Digital Zoom Capability
Adjustable Aperture Range of f2.8 to f11
Powerful Telephoto Zoom
Collect high-definition images from a safe distance with 16x digital zoom that supports 3x lossless zoom.
Mission Versatility
With an expanded selection of accessories at its disposal, the EVO II Enterprise can evolve from a simple imaging tool to a multifunctional flight platform that can adapt to different scenarios.
Reliable Data Encryption
Protect sensitive information through encrypted internal and external storage, allowing users to work with confidence.
ADS-B Receiver
Detects the presence of any manned aircraft nearby emitting an ADS-B signal, giving the operator enough time to take evasive measures to avoid mid-air collisions.
Predictive Target Tracking
Lock on to an object moving at high speed and predict its trajectory with ease, or use the eye in the sky to identify up to 64 objects at once.
Practical Use Cases
Inspection
Zip between power lines to quickly spot structural damage or overheating electrical elements, saving time and labor costs.
Traffic Supervision
Monitor traffic flow over a larger area and crack down on traffic violations to improve safety for everyone on the road.
Surveying & mapping
Create cost-effective 3D maps of an area using high-resolution images captured during steady, consistent flight.
Search and Rescue
Quickly locate missing persons by using automated mission modes to cover larger search areas in situations where every second counts.
Specifications
| Takeoff Weight(Without Accessories) | EVO II Pro Enterprise：2.45 lbs (1110 g) |
| Diagonal Length | 16.8 inches (427 mm) |
| Size(L*W*H, propeller included) | 506*620*111mm (Unfolded) 245*130*111mm (Folded) |
| Max Flight Time (no wind) | 42 min（without accessories） |
| Max Hovering Time (no wind) | 38 min（with strobe） 29 min（with spotlight） 34 min（with loudspeaker） 36 min（with RTK module） |
| Max Level Flight Speed | 45 mph (20 m/s) (Ludicrous) |
| Max Ascent Speed | 18 mph (8 m/s (Ludicrous) |
| Max Descent Speed | 9 mph (4 m/s) (Ludicrous) |
| Max Service Ceiling Altitude | 4.3 miles (7000 m) MSL |
| Operating Temperature Range | 14℉ to 104℉ (-10℃ to 40℃) |
| Max Wind Speed Resistance | 39 - 46 mph (17-20 m/s) |
| Operating Frequency | 2.400 GHz - 2.4835 GHz； 5.725GHz - 5.850 GHz |
| Hovering Accuracy Range | Vertical: ± 0.1 m (with RTK) ± 0.1 m (with Vision Positioning) ± 0.5 m (with GPS Positioning) Horizontal: ± 0.1 m (with RTK) ± 0.3 m (with Vision Positioning) ± 1.5 m (with GPS Positioning) |
| Operation Range | Pitch: -135° to +45° Yaw: -100° to +100° |
| Operation Range | Pitch: -90° to +30° Yaw: -90° to +90° |
| Stability | More Stable with 3 Axies |
| Max Control Speed (Tilt) | 300°/s |
| Angular Vibration Range | ±0.005° |
| Sensing System Type | Omnidirectional Binocular Sensing System |
| Forward | Accurate Measuring Range: 0.5 - 20m Detection Range: 0.5 - 40m Effective Sensing Speed: < 15 m/s FOV: Horizontal: 60°, Vertical: 80° |
| Backward | Accurate Measuring Range: 0.5 - 16m Detection Range: 0.5 - 32m Effective Sensing Speed: < 12 m/s FOV: Horizontal: 60°, Vertical: 80° |
| Upward | Accurate Measuring Range: 0.5 - 12m Detection Range: 0.5 - 24m Effective Sensing Speed: < 6 m/s FOV: Horizontal: 65°, Vertical: 50° |
| Downward | Accurate Measuring Range: 0.5 - 11m Detection Range: 0.5 - 22m Effective Sensing Speed: < 6 m/s FOV: Horizontal: 100°, Vertical: 80° |
| Sides | Accurate Measuring Range: 0.5 - 12m Detection Range: 0.5 - 24m Effective Sensing Speed: < 10 m/s FOV: Horizontal: 65°, Vertical: 50° |
| Service Environment | Forward, Backward and Sides: Surface with clear pattern and adequate lighting (lux > 15) Upward: Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) Downward: Surface with clear pattern and adequate lighting (lux > 15) Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) |
| Sensor | 1 inch CMOS; 20 million effective pixels |
| FOV | 82° |
| Aperture | f/2.8 - f/11 |
| Focus range | 1m to ∞ |
| Equivalent Focal Length | 28.6mm |
| ISO Range | Video: 100-6400 (auto) Photo: 100-12800 (auto) |
| Zoom | 1-16x (up to 3x lossless zoom) |
| Still Photography Modes | Single Shot Burst shooing: 3/5 frames Automatic Exposure Bracketing (AEB)： 3/5 bracketed frames at 0.7 EV Bias Timelapse： JPG：2s/5s/7s/10s/20s/30s/60s DNG：5s/7s/10s/20s/30s/60s HyperLight：support (under 4K JPEG format） Long Exposure: Max 8s HDR imaging: (under 4K JPEG) |
| Still Photography Resolution | 5472*3648 (3:2) 5472*3076 (16:9) 3840*2160 (16:9) |
| Video Format | MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) |
| Video Resolution | 6K 5472*3076 p30/p25/p24 4K 3840*2160 p60/p50/p48/p30/p25/p24 2.7K 2720*1528 p120/p60/p50/p48/p30/p25/p24 1080p 1920*1080 p120/p60/p50/p48/p30/p25/p24 |
| Max Bitrate | 120Mbps |
| *Operating Frequency | 902-928 MHz; 2.400-2.4835 GHz; 5.725-5.850 GHz |
| Max Transmission Distance (unobstructed, free of interference) | FCC: 13km CE: 7km |
| Transmitter Power (EIRP) | 902-928 MHz FCC:≤30dBm 2.400-2.4835 GHz FCC:≤30dBm CE：≤20dBm 5.725-5.850 GHz CE：≤14dBm |
| Internal Storage | 128GB |
| Video Output Port | HDMI |
| Built-in Battery | Name: Intelligent Li-ion battery Capacity：5800mAh Voltage：11.55V Battery Type：Li-ion Battery Energy：67 Wh Charging time：120 min |
| Battery Life | 3hr (Max. intensity) 4.5hr (50% intensity) |
| Operating Temperature | -20℃ - 40℃ |
| RC Size | 303 x 190 x 87 mm (Ant. folded) 303 x 273 x 87 mm (Ant. unfolded) |
| Weight | 1150g (Without protective case) 1250g (With protective case) |
| Satellite Positioning Module | GPS + GLONASS + Galileo |
| Note: *The operating frequency band varies according to different countries and areas. | |
| Capacity | 7100 mAh |
| Voltage | 11.55 V |
| Battery Type | LiPo 3S |
| Energy | 82Wh |
| Net Weight | 365g |
| Charging Temperature | 5~45℃ |
| Storage Temperature & Humidity | -10~30℃，65±20%RH |
| Recommended Storage Temperature | 22~28℃ |
| Max Charging Power | 93 W |
| Charging Time | 90 mins |
| Input | 100-240 V, 50/60 Hz, 1.5A |
| Output | 13.2 V ⎓ 5 A 5V⎓3A 9V⎓2A 12V⎓1.5A |
| Voltage | 13.2 ± 0.1 V |
| Rated Power | 66 W |
| Strobe | Dimensions：39*72*34 mm |
| Weight：19.5 g | |
| Connections：Floating Connectors | |
| Power：Avg. 1.6W | |
| Controllable Range：5000 m | |
| Light intensity：Min 50cd；Max 486cd；Avg. 290cd | |
| Loudspeaker | Dimensions：46*80*77 mm |
| Weight：98.5 g | |
| Connections：Floating Connectors | |
| Power：Max 18W | |
| Decibel：120dB @ 1m；88dB @ 60m；70dB @ 110m； | |
| Max Bitrate：36kbps | |
| Adjustable Angle Range：0°~45° | |
| Spotlight | Dimensions：48.5*72*63 mm |
| Weight：77 g | |
| Connections：Floating Connectors | |
| Power：Max 35W | |
| Controllable Range：30 m | |
| Adjustable Angle Range：0°~90° | |
| Illuminance：FOV14°, Max：11lux @ 30m Straight | |
| RTK Module(Optional) | Dimensions：55.5*72.5*57 mm |
| Weight：59.5 g | |
| Connections：Floating Connectors | |
| Power：~ 3W | |
| RTK Positioning Precision： 1.5 cm + 1 ppm（(Vertical） 1 cm + 1 ppm（Horizontal） |
| Internal Storage | 8 G |
| SD Storage | Standard: 32 GB Max. support 256GB （ UHS-3 rating required ） |
Packing List
FAQ
Compared with other products in the EVO II series, it mainly adds industry expansion accessories (spotlight, loudspeaker, strobe, RTK modules).
The EVO II industry version comes standard with an Autel smart remote control, equipped with a 7.9-inch retina touch screen, using True Tone display technology, with a resolution of 2048*1536 and a maximum brightness of 2000nit, four times that of ordinary mobile devices. And it is compatible with other models of EVO II series drones.
902-928 MHz; 2.400-2.4835 GHz; 5.725–5.850 GHz.
*Working frequency bands vary by country and model.
It can assist the camera to shoot within about 30 meters.
There is a spotlight icon in the lower left corner of the image transmission interface, and you can click to turn off/on the spotlight or select the intensity of irradiation.
After testing, in an environment of 65db, the sound intensity of the drone at different distances from the test point is: 120dB@1m; 88dB@60m; 70dB@110m.
Depending on the actual environment, the maximum distance can be up to 5000 meters.
Disassembly accessories
1) Make sure the aircraft power is off.
2) Loosen the screws on both sides of the accessory and remove the accessory.
3) Insert both ends of the protective cover into the corresponding slots.
Mounting Accessories
1) Make sure the aircraft power is off.
2) Gently twist to remove the protective cover of the expansion accessory interface.
3) Align the screws on both sides of the accessory with the screw holes, and tighten the screws
It takes about 90 minutes to fully charge each battery.
If the battery is used in a low temperature environment, the battery life will be reduced, please arrange the flight time reasonably. To get the best performance from the battery, it is recommended to keep the battery temperature above 15 °C before flying.
